Appendix A. Schematic and Layouts
A.1 INTRODUCTION
This appendix contains the following schematics and layouts for the MCP6031
Photodiode PICtail™ Plus Demo Board :
• Board – Schematic
• Board – Top Silk Layer
• Board - Top Metal And Top Silk Layers
• Board – Bottom Metal Layer
