MCP1631HV Digitally Controlled Programmable Current Source Reference Design
DS51798A-page 24 © 2009 Microchip Technology Inc.
1 R21 RES 3.92K OHM 1/8W 1% 0805
SMD
Panasonic - ECG ERJ-6ENF3921V
1 R24 RES 0.0 OHM 1/8W 5% 0805 SMD Panasonic - ECG ERJ-6GEY0R00V
1 R4 RES 39.2K OHM 1/8W 1% 0805
SMD
Panasonic - ECG ERJ-6ENF3922V
2 R6, R7 RES 1.00K OHM 1/8W 1% 0805
SMD
Panasonic - ECG ERJ-6ENF1001V
1 U1 MCP1631HV 3.3V 20 Pin TSSOP
High Speed PWM
Microchip Technology Inc. MCP1631HV-330E/ST
1 U2 IC PIC MCU 14-Pin Flash-Based,
8-Bit CMOS MCU
Microchip Technology Inc. PIC16F616-I/SL
TABLE B-1: BILL OF MATERIALS (CONTINUED)
Qty Reference Description Manufacturer Part Number
Note 1: The components listed in this Bill of Materials are representative of the PCB assembly. The
released BOM used in manufacturing uses all RoHS-compliant components.
