FIGURE 2-3: NiMH Three-Cell (3.6V/600 mAh) Charged at Maximum 0.75C.
0.0
1.0
2.0
3.0
4.0
5.0
0 20406080100
Time (min)
Volts,°C/10
0.0
0.2
0.4
0.6
0.8
1.0
Amps
T/10
V
BAT
I
OUT
