MCP1403/4/5
DS22022B-page 2 © 2007 Microchip Technology Inc.
Functional Block Diagram
(1)
Effective
Input C = 20 pF
MCP1403 Dual Inverting
MCP1404 Dual Non-inverting
Input
GND
V
DD
300 mV
4.7V
Inverting
Non-inverting
Note 1: Unused inputs should be grounded.
730 µA
Output
(Each Input)
MCP1405 Inverting / Non-inverting
