MCP1403/4/5
DS22022B-page 12 © 2007 Microchip Technology Inc.
5.0 PACKAGING INFORMATION
5.1 Package Marking Information (Not to Scale)
XXXXXXXX
XXXXXNNN
YYWW
8-Lead PDIP (300 mil)
Example:
MCP1403
E/P^^256
0648
8-Lead SOIC (150 mil)
Example:
256
MCP1405E
8-Lead DFN
Example
:
XXXXXXX
XXXXXXX
XXYYWW
NNN
MCP1403
E/MF^^
0648
256
SN^^0648
Legend: XX...X Customer-specific information
Y Year code (last digit of calendar year)
YY Year code (last 2 digits of calendar year)
WW Week code (week of January 1 is week ‘01’)
NNN Alphanumeric traceability code
Pb-free JEDEC designator for Matte Tin (Sn)
* This package is Pb-free. The Pb-free JEDEC designator ( )
can be found on the outer packaging for this package.
Note: In the event the full Microchip part number cannot be marked on one line, it will
be carried over to the next line, thus limiting the number of available
characters for customer-specific information.
3
e
3
e
3
e
3
e
3
e
NNN
XXXXXXXX
XXXXYYWW
16-Lead SOIC (300 mil)
Example:
XXXXXXXXXXX
XXXXXXXXXXX
YYWWNNN
XXXXXXXXXXX
0648256
MCP1405
E/SO^^
3
e
