MCP111/112
DS21889E-page 10 2004-2013 Microchip Technology Inc.
3.0 PIN DESCRIPTION
The descriptions of the pins are listed in Table 3-1.
TABLE 3-1: PIN FUNCTION TABLE
Pin No.
Symbol Function
SOT-23-3
SC-70
SOT-89-3 T0-92
111V
OUT
Output State
V
DD
Falling:
H = V
DD
> V
TRIP
L = V
DD
< V
TRIP
V
DD
Rising:
H = V
DD
> V
TRIP
+ V
HYS
L = V
DD
< V
TRIP
+ V
HYS
223V
SS
Ground reference
332V
DD
Positive power supply
—4—V
DD
Positive power supply
