dsPIC30F6011A/6012A/6013A/6014A

TABLE 23-11: ELECTRICAL CHARACTERISTICS: BOR

DC CHARACTERISTICS

Standard Operating Conditions: 2.5V to 5.5V

(unless otherwise stated)

Operating temperature -40°C ≤ TA ≤ +85°C for Industrial

-40°C ≤ T

A ≤ +125°C for Extended

Param

No.

Symbol Characteristic Min Typ

(1)

Max Units Conditions

BO10 V

BOR BOR Voltage

(2)

VDD transition high to

low

BORV = 11

(3)

— — — V Not in operating

range

BORV = 10 2.6 — 2.71 V

BORV = 01 4.1 — 4.4 V

BORV = 00 4.58 — 4.73 V

BO15 V

BHYS —5—mV

Note 1: Data in “Typ” column is at 5V, 25°C unless otherwise stated. Parameters are for design guidance only and

are not tested.

2: These parameters are characterized but not tested in manufacturing.

3: ’11’ values not in usable operating range.

TABLE 23-12: DC CHARACTERISTICS: PROGRAM AND EEPROM

DC CHARACTERISTICS

Standard Operating Conditions: 2.5V to 5.5V

(unless otherwise stated)

Operating temperature -40°C ≤ TA ≤ +85°C for Industrial

-40°C ≤ TA ≤ +125°C for Extended

Param

No.

Symbol Characteristic Min Typ

(1)

Max Units Conditions

Data EEPROM Memory

(2)

D120 ED Byte Endurance 100K 1M — E/W -40° C ≤ TA ≤ +85°C

D121 VDRW VDD for Read/Write VMIN — 5.5 V Using EECON to read/write

VMIN = Minimum operating

voltage

D122 TDEW Erase/Write Cycle Time 0.8 2 2.6 ms RTSP

D123 T

RETD Characteristic Retention 40 100 — Year Provided no other specifications

are violated

D124 IDEW IDD During Programming — 10 30 mA Row Erase

Program FLASH Memory

(2)

D130 EP Cell Endurance 10K 100K — E/W -40° C ≤ TA ≤ +85°C

D131 VPR VDD for Read VMIN —5.5VVMIN = Minimum operating

voltage

D132 V

EB VDD for Bulk Erase 4.5 — 5.5 V

D133 VPEW VDD for Erase/Write 3.0 — 5.5 V

D134 T

PEW Erase/Write Cycle Time 0.8 2 2.6 ms RTSP

D135 T

RETD Characteristic Retention 40 100 — Year Provided no other specifications

are violated

D137 I

PEW IDD During Programming — 10 30 mA Row Erase

D138 I

EB IDD During Programming — 10 30 mA Bulk Erase

Note 1: Data in “Typ” column is at 5V, 25°C unless otherwise stated.

2: These parameters are characterized but not tested in manufacturing.
