dsPIC30F6011A/6012A/6013A/6014A

TABLE 23-5: DC CHARACTERISTICS: OPERATING CURRENT (IDD)

DC CHARACTERISTICS

Standard Operating Conditions: 2.5V to 5.5V

(unless otherwise stated)

Operating temperature -40°C ≤ TA ≤ +85°C for Industrial

-40°C ≤ T

A ≤ +125°C for Extended

Parameter

No.

Typical

(1)

Max Units Conditions

Operating Current (I

DD)

(2)

DC31a 3.1 6 mA 25°C

3.3V

0.128 MIPS

LPRC (512 kHz)

DC31b 3.2 6 mA 85°C

DC31c 3.1 6 mA 125°C

DC31e 5.7 9 mA 25°C

5VDC31f 5.5 9 mA 85°C

DC31g 5.5 9 mA 125°C

DC30a 10 15 mA 25°C

3.3V

(1.8 MIPS)

FRC (7.37 MHz)

DC30b 10 15 mA 85°C

DC30c 10 15 mA 125°C

DC30e 17 26 mA 25°C

5VDC30f 17 26 mA 85°C

DC30g 17 26 mA 125°C

DC23a 19 30 mA 25°C

3.3V

4 MIPS

DC23b 20 30 mA 85°C

DC23c 20 30 mA 125°C

DC23e 32 50 mA 25°C

5VDC23f 32 50 mA 85°C

DC23g 33 50 mA 125°C

DC24a 45 68 mA 25°C

3.3V

10 MIPS

DC24b 45 68 mA 85°C

DC24c 46 68 mA 125°C

DC24e 74 105 mA 25°C

5VDC24f 74 105 mA 85°C

DC24g 75 105 mA 125°C

DC27d 140 180 mA 25°C

5V 20 MIPSDC27e 138 180 mA 85°C

DC27f 138 180 mA 125°C

DC29a 203 250 mA 25°C

5V 30 MIPS

DC29b 202 250 mA 85°C

Note 1: Data in “Typ” column is at 5V, 25°C unless otherwise stated. Parameters are for design guidance only and

are not tested.

2: The supply current is mainly a function of the operating voltage and frequency. Other factors such as I/O

pin loading and switching rate, oscillator type, internal code execution pattern and temperature also have

an impact on the current consumption. The test conditions for all I

DD measurements are as follows: OSC1

driven with external square wave from rail to rail. All I/O pins are configured as Inputs and pulled to V

DD.

MCLR = VDD, WDT, FSCM, LVD and BOR are disabled. CPU, SRAM, Program Memory and Data Memory

are operational. No peripheral modules are operating.
