dsPIC30F6011A/6012A/6013A/6014A
DS70143E-page 132 © 2011 Microchip Technology Inc.
TABLE 18-2: DCI REGISTER MAP
(1)
SFR Name Addr. Bit 15 Bit 14 Bit 13 Bit 12 Bit 11 Bit 10 Bit 9 Bit 8 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Reset State
DCICON1 0240 DCIEN
— DCISIDL — DLOOP CSCKD CSCKE COFSD UNFM CSDOM DJST — — — COFSM1 COFSM0 0000 0000 0000 0000
DCICON2 0242
— — — —BLEN1BLEN0 —COFSG<3:0>— WS<3:0> 0000 0000 0000 0000
DCICON3 0244
— — — —BCG<11:0>0000 0000 0000 0000
DCISTAT 0246
— — — — SLOT3 SLOT2 SLOT1 SLOT0 — — — — ROV RFUL TUNF TMPTY 0000 0000 0000 0000
TSCON 0248 TSE15 TSE14 TSE13 TSE12 TSE11 TSE10 TSE9 TSE8 TSE7 TSE6 TSE5 TSE4 TSE3 TSE2 TSE1 TSE0 0000 0000 0000 0000
RSCON 024C RSE15 RSE14 RSE13 RSE12 RSE11 RSE10 RSE9 RSE8 RSE7 RSE6 RSE5 RSE4 RSE3 RSE2 RSE1 RSE0 0000 0000 0000 0000
RXBUF0 0250 Receive Buffer 0 Data Register 0000 0000 0000 0000
RXBUF1 0252 Receive Buffer 1 Data Register 0000 0000 0000 0000
RXBUF2 0254 Receive Buffer 2 Data Register 0000 0000 0000 0000
RXBUF3 0256 Receive Buffer 3 Data Register 0000 0000 0000 0000
TXBUF0 0258 Transmit Buffer 0 Data Register 0000 0000 0000 0000
TXBUF1 025A Transmit Buffer 1 Data Register 0000 0000 0000 0000
TXBUF2 025C Transmit Buffer 2 Data Register 0000 0000 0000 0000
TXBUF3 025E Transmit Buffer 3 Data Register 0000 0000 0000 0000
Legend: — = unimplemented bit, read as ‘0’
Note 1: Refer to the “dsPIC30F Family Reference Manual” (DS70046) for descriptions of register bit fields.
