dsPIC30F6011/6012/6013/6014
DS70117F-page 66 © 2006 Microchip Technology Inc.
TABLE 8-5: PORTD REGISTER MAP FOR dsPIC30F6011/6012
TABLE 8-6: PORTD REGISTER MAP FOR dsPIC30F6013/6014
TABLE 8-7: PORTF REGISTER MAP FOR dsPIC30F6011/6012
TABLE 8-8: PORTF REGISTER MAP FOR dsPIC30F6013/6014
TABLE 8-9: PORTG REGISTER MAP FOR dsPIC30F6011/6012/6013/6014
SFR
Name
Addr. Bit 15 Bit 14 Bit 13 Bit 12 Bit 11 Bit 10 Bit 9 Bit 8 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Reset State
TRISD 02D2
— — — —
TRISD11
TRISD10 TRISD9 TRISD8 TRISD7 TRISD6 TRISD5 TRISD4 TRISD3 TRISD2 TRISD1 TRISD0 0000 1111 1111 1111
PORTD 02D4
— — — — RD11 RD10 RD9 RD8 RD7 RD6 RD5 RD4 RD3 RD2 RD1 RD0 0000 0000 0000 0000
LATD 02D6
— — — — LATD11 LATD10 LATD9 LATD8 LATD7 LATD6 LATD5 LATD4 LATD3 LATD2 LATD1 LATD0 0000 0000 0000 0000
Note: Refer to “dsPIC30F Family Reference Manual” (DS70046) for descriptions of register bit fields.
SFR
Name
Addr. Bit 15 Bit 14 Bit 13 Bit 12 Bit 11 Bit 10 Bit 9 Bit 8 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Reset State
TRISD 02D2 TRISD15 TRISD14 TRISD13 TRISD12
TRISD11
TRISD10 TRISD9 TRISD8 TRISD7 TRISD6 TRISD5 TRISD4 TRISD3 TRISD2 TRISD1 TRISD0 1111 1111 1111 1111
PORTD 02D4 RD15 RD14 RD13 RD12 RD11 RD10 RD9 RD8 RD7 RD6 RD5 RD4 RD3 RD2 RD1 RD0 0000 0000 0000 0000
LATD 02D6 LATD15 LATD14 LATD13 LATD12 LATD11 LATD10 LATD9 LATD8 LATD7 LATD6 LATD5 LATD4 LATD3 LATD2 LATD1 LATD0 0000 0000 0000 0000
Note: Refer to “dsPIC30F Family Reference Manual” (DS70046) for descriptions of register bit fields.
SFR
Name
Addr. Bit 15 Bit 14 Bit 13 Bit 12 Bit 11 Bit 10 Bit 9 Bit 8 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Reset State
TRISF 02DE
— — — — — — — — — TRISF6 TRISF5 TRISF4 TRISF3 TRISF2 TRISF1 TRISF0 0000 0000 0111 1111
PORTF 02E0
— — — — — — — — — RF6 RF5 RF4 RF3 RF2 RF1 RF0 0000 0000 0000 0000
LATF 02E2
— — — — — — — — — LATF6 LATF5 LATF4 LATF3 LATF2 LATF1 LATF0 0000 0000 0000 0000
Note: Refer to “dsPIC30F Family Reference Manual” (DS70046) for descriptions of register bit fields.
SFR
Name
Addr. Bit 15 Bit 14 Bit 13 Bit 12 Bit 11 Bit 10 Bit 9 Bit 8 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Reset State
TRISF 02DE
— — — — — — — TRISF8 TRISF7 TRISF6 TRISF5 TRISF4 TRISF3 TRISF2 TRISF1 TRISF0 0000 0001 1111 1111
PORTF 02E0
— — — — — — — RF8 RF7 RF6 RF5 RF4 RF3 RF2 RF1 RF0 0000 0000 0000 0000
LATF 02E2
— — — — — — — LATF8 LATF7 LATF6 LATF5 LATF4 LATF3 LATF2 LATF1 LATF0 0000 0000 0000 0000
Note: Refer to “dsPIC30F Family Reference Manual” (DS70046) for descriptions of register bit fields.
SFR
Name
Addr. Bit 15 Bit 14 Bit 13 Bit 12 Bit 11 Bit 10 Bit 9 Bit 8 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Reset State
TRISG 02E4 TRISG15 TRISG14 TRISG13 TRISG12
— — TRISG9 TRISG8 TRISG7 TRISG6 — — TRISG3 TRISG2 TRISG1 TRISG0 1111 0011 1100 1111
PORTG 02E6 RG15 RG14 RG13 RG12
— — RG9 RG8 RG7 RG6 — — RG3 RG2 RG1 RG0 0000 0000 0000 0000
LATG 02E8 LATG15 LATG14 LATG13 LATG12
— — LATG9 LATG8 LATG7 LATG6 — — LATG3 LATG2 LATG1 LATG0 0000 0000 0000 0000
Note: Refer to “dsPIC30F Family Reference Manual” (DS70046) for descriptions of register bit fields.
