© 2006 Microchip Technology Inc. DS70117F-page 55
dsPIC30F6011/6012/6013/6014
TABLE 6-1: NVM REGISTER MAP
File Name Addr. Bit 15 Bit 14 Bit 13 Bit 12 Bit 11 Bit 10 Bit 9 Bit 8 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 All RESETS
NVMCON 0760 WR WREN WRERR
— — — —TWRI — PROGOP<6:0> 0000 0000 0000 0000
NVMADR 0762 NVMADR<15:0> uuuu uuuu uuuu uuuu
NVMADRU 0764
— — — — — — — — NVMADR<23:16> 0000 0000 uuuu uuuu
NVMKEY 0766
— — — — — — — — KEY<7:0> 0000 0000 0000 0000
Legend: u = uninitialized bit
Note: Refer to “dsPIC30F Family Reference Manual” (DS70046) for descriptions of register bit fields.
