dsPIC30F6011/6012/6013/6014
DS70117F-page 2 © 2006 Microchip Technology Inc.
Special Microcontroller Features (Cont.):
• Fail-Safe Clock Monitor operation:
- Detects clock failure and switches to on-chip
low power RC oscillator
• Programmable code protection
• In-Circuit Serial Programming™ (ICSP™)
• Selectable Power Management modes:
- Sleep, Idle and Alternate Clock modes
CMOS Technology:
• Low-power, high-speed Flash technology
• Wide operating voltage range (2.5V to 5.5V)
• Industrial and Extended temperature ranges
• Low power consumption
dsPIC30F6011/6012/6013/6014 Controller Families
Device Pins
Program Memory
SRAM
Bytes
EEPROM
Bytes
Timer
16-bit
Input
Cap
Output
Comp/Std
PWM
Codec
Interface
A/D 12-bit
200 ksps
UART
SPI
I
2
C™
CAN
Bytes Instructions
dsPIC30F6011 64 132K 44K 6144 2048 5 8 8 — 16 ch 2 2 1 2
dsPIC30F6012 64 144K 48K 8192 4096 5 8 8 AC’97, I
2
S 16 ch 2 2 1 2
dsPIC30F6013 80 132K 44K 6144 2048 5 8 8 — 16 ch 2 2 1 2
dsPIC30F6014 80 144K 48K 8192 4096 5 8 8 AC’97, I
2
S 16 ch 2 2 1 2
