© 2006 Microchip Technology Inc. DS70117F-page 207
dsPIC30F6011/6012/6013/6014
AD24A EOFF Offset Error -2 -1.5 -1.25 LSb VINL = AVSS = VREFL =
0V, AV
DD = VREFH = 3V
AD25 — Monotonicity
(3)
— — — — Guaranteed
Dynamic Performance
AD30 THD Total Harmonic Distortion — -71 — dB —
AD31 SINAD Signal to Noise and
Distortion
—68—dB —
AD32 SFDR Spurious Free Dynamic
Range
—83—dB —
AD33 F
NYQ Input Signal Bandwidth — — 100 kHz —
AD34 ENOB Effective Number of Bits 10.95 11.1 — bits —
TABLE 23-38: 12-BIT ADC MODULE SPECIFICATIONS (CONTINUED)
AC CHARACTERISTICS
Standard Operating Conditions: 2.7V to 5.5V
(unless otherwise stated)
Operating temperature -40°C ≤ TA ≤ +85°C for Industrial
-40°C ≤ T
A ≤ +125°C for Extended
Param
No.
Symbol Characteristic Min. Typ Max. Units Conditions
Note 1: These parameters are characterized but not tested in manufacturing.
2: Measurements taken with external V
REF+ and VREF- used as the ADC voltage references.
3: The A/D conversion result never decreases with an increase in the input voltage, and has no missing
codes.
