dsPIC30F6011/6012/6013/6014
Note 1: Assumption: Oscillator Postscaler is divide by 1.
2: Instruction Execution Cycle Time: TCY = 1 / MIPS.
3: Instruction Execution Frequency: MIPS = (F
OSC * PLLx)/4 [since there are 4 Q clocks per instruction
cycle].
TABLE 23-17: INTERNAL CLOCK TIMING EXAMPLES
TABLE 23-18: AC CHARACTERISTICS: INTERNAL RC ACCURACY
(2)
AC CHARACTERISTICS
Standard Operating Conditions: 2.5V to 5.5V
(unless otherwise stated)
Operating temperature -40°C ≤ T
A ≤ +85°C for Industrial
-40°C ≤ T
A ≤ +125°C for Extended
Param
No.
Characteristic Min Typ Max Units Conditions
Internal FRC Jitter @ FRC Freq. = 7.37 MHz
(1)
OS62 FRC — +0.04 +0.16 % -40°C ≤ TA ≤ +85°C VDD = 3.0-3.6V
—+0.07 +0.23 % -40°C ≤ TA ≤ +125°C VDD = 4.5-5.5V
Internal FRC Accuracy @ FRC Freq. = 7.37 MHz
(1)
OS63 FRC — — +1.50 % -40°C ≤ TA ≤ +125°C VDD = 3.0-5.5V
Internal FRC Drift @ FRC Freq. = 7.37 MHz
(1)
OS64 -0.7 — 0.5 % -40°C ≤ TA ≤ +85°C VDD = 3.0-3.6V
-0.7 — 0.7 % -40°C ≤ TA ≤ +125°C VDD = 3.0-3.6V
-0.7 — 0.5 % -40°C ≤ TA ≤ +85°C VDD = 4.5-5.5V
-0.7 — 0.7 % -40°C ≤ T
A ≤ +125°C VDD = 4.5-5.5V
Note 1: Frequency calibrated at 7.372 MHz ±2%, 25°C and 5V. TUN <3:0> bits can be used to compensate for
temperature drift.
2: Overall FRC variation can be calculated by adding the absolute values of jitter, accuracy and drift percent-
ages.
TABLE 23-19: INTERNAL RC ACCURACY
AC CHARACTERISTICS
Standard Operating Conditions: 2.5V to 5.5V
(unless otherwise stated)
Operating temperature -40°C ≤ TA ≤ +85°C for Industrial
-40°C ≤ T
A ≤ +125°C for Extended
Param
No.
Characteristic Min Typ Max Units Conditions
LPRC @ Freq. = 512 kHz
(1)
OS65 -35 — +35 % —
Note 1: Change of LPRC frequency as V
DD changes.
