dsPIC30F6011A/6012A/6013A/6014A
DS70143E-page 94 © 2011 Microchip Technology Inc.
TABLE 14-1: SPI1 REGISTER MAP
(1)
TABLE 14-2: SPI2 REGISTER MAP
(1)
SFR
Name
Addr. Bit 15 Bit 14 Bit 13 Bit 12 Bit 11 Bit 10 Bit 9 Bit 8 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Reset State
SPI1STAT 0220 SPIEN
— SPISIDL — — — — — — SPIROV — — — —SPITBFSPIRBF0000 0000 0000 0000
SPI1CON 0222
— FRMEN SPIFSD — DISSDO MODE16 SMP CKE SSEN CKP MSTEN SPRE2 SPRE1 SPRE0 PPRE1 PPRE0 0000 0000 0000 0000
SPI1BUF 0224 Transmit and Receive Buffer 0000 0000 0000 0000
Legend: — = unimplemented bit, read as ‘0’
Note 1: Refer to the “dsPIC30F Family Reference Manual” (DS70046) for descriptions of register bit fields.
SFR Name Addr. Bit 15 Bit 14 Bit 13 Bit 12 Bit 11 Bit 10 Bit 9 Bit 8 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Reset State
SPI2STAT 0226 SPIEN
— SPISIDL — — — — — —SPIROV — — — — SPITBF SPIRBF 0000 0000 0000 0000
SPI2CON 0228
— FRMEN SPIFSD — DISSDO MODE16 SMP CKE SSEN CKP MSTEN SPRE2 SPRE1 SPRE0 PPRE1 PPRE0 0000 0000 0000 0000
SPI2BUF 022A Transmit and Receive Buffer 0000 0000 0000 0000
Legend: — = unimplemented bit, read as ‘0’
Note 1: Refer to the “dsPIC30F Family Reference Manual” (DS70046) for descriptions of register bit fields.
