dsPIC30F6011A/6012A/6013A/6014A
DS70143E-page 4 © 2011 Microchip Technology Inc.
CMOS Technology:
• Low-power, high-speed Flash technology
• Wide operating voltage range (2.5V to 5.5V)
• Industrial and Extended temperature ranges
• Low power consumption
dsPIC30F6011A/6012A/6013A/6014A Controller Families
Device Pins
Program Memory
SRAM
Bytes
EEPROM
Bytes
Timer
16-bit
Input
Cap
Output
Comp/Std
PWM
Codec
Interface
ADC
12-bit
100 Ksps
UART
SPI
I
2
C™
CAN
Bytes Instructions
dsPIC30F6011A 64 132K 44K 6144 2048 5 8 8 — 16 ch 2 2 1 2
dsPIC30F6012A 64 144K 48K 8192 4096 5 8 8 AC’97, I
2
S16 ch 2212
dsPIC30F6013A 80 132K 44K 6144 2048 5 8 8 — 16 ch 2 2 1 2
dsPIC30F6014A 80 144K 48K 8192 4096 5 8 8 AC’97, I
2
S16 ch 2212
