Graphics Quick Reference Guide 11

Widget API (Continued)

Chart4 Round Dial Check Box Digital Meter Edit Box

GFX_COLOR *ChGetColorTable(

CHART* pObj)

Graphics Cong: USE_ROUNDDIAL Graphics Cong: USE_CHECKBOX Graphics Cong: USE_DIGITALMETER Graphics Cong: USE_EDITBOX

void *ChGetAxisLabelFont(CHART *pObj) ROUNDDIAL * RdiaCreate(

WORD ID,

SHORT x,

SHORT y,

SHORT radius,

WORD state,

SHORT res,

SHORT value,

SHORT max,

GOL_SCHEME * pScheme)

CHECKBOX * CbCreate(

WORD ID,

SHORT left,

SHORT top,

SHORT right,

SHORT bottom,

WORD state,

XCHAR * pText,

GOL_SCHEME * pScheme)

DIGITALMETER * DmCreate(

WORD ID,

SHORT left,

SHORT top,

SHORT right,

SHORT bottom,

WORD state,

DWORD Value,

BYTE NoOfDigits,

BYTE DotPos,

GOL_SCHEME * pScheme)

EDITBOX * EbCreate(

WORD ID,

SHORT left,

SHORT top,

SHORT right,

SHORT bottom,

WORD state,

XCHAR * pText,

WORD charMax,

GOL_SCHEME * pScheme)

void ChSetAxisLabelFont(

CHART *pObj,

void* pFont)

WORD RdiaDraw(void * pObj) WORD CbDraw(void * pObj) WORD DmDraw(void * pObj) WORD EbDraw(void * pObj)

void *ChGetGridLabelFont(CHART *pObj) void RdiaIncVal(ROUNDDIAL *pObj) XCHAR *CbGetText(CHECKBOX pObj) WORD DmGetValue(DIGITALMETER *pObj) XCHAR *EbGetText(EDITBOX pObj)

void ChSetGridLabelFont(

CHART *pObj,

void* pFont)

void RdiaDecVal(ROUNDDIAL *pObj) void CbSetText(

CHECKBOX pObj,

XCHAR *pText)

void DmSetValue(

DIGITALMETER *pObj,

WORD value)

void EbSetText(

EDITBOX pObj,

XCHAR *pText)

void ChFreeDataSeries(

void * pObj)

WORD RdiaGetVal(ROUNDDIAL *pObj) void CbMsgDefault(

WORD translatedMsg,

void * pObj,

GOL_MSG * pMsg)

void DmIncVal(

DIGITALMETER *pObj,

WORD deltaValue)

void EbAddChar(

EDITBOX * pObj,

XCHAR ch)

WORD ChTranslateMsg(

void * pObj,

GOL_MSG * pMsg)

void RdiaSetVal(ROUNDDIAL *pObj, WORD value) WORD CbTranslateMsg(

void * pObj,

GOL_MSG * pMsg)

void DmDecVal(

DIGITALMETER *pObj,

WORD deltaValue)

void EbDeleteChar(EDITBOX *

pObj)

typedef struct {

OBJ_HEADER hdr;

CHARTPARAM prm;

DATASERIES * pChData;

} CHART;

void RdiaMsgDefault(

WORD translatedMsg,

void * pObj,

GOL_MSG * pMsg)

typedef struct {

OBJ_HEADER hdr;

SHORT textHeight;

XCHAR * pText;

} CHECKBOX;

WORD DmTranslateMsg(

void * pObj,

GOL_MSG * pMsg)

void EbMsgDefault(

WORD translatedMsg,

void * pObj,

GOL_MSG * pMsg

)

typedef struct {

XCHAR * pSData;

WORD samples;

BYTE show;

WORD * pData;

void * pNextData;

} DATASERIES;

WORD RdiaTranslateMsg(

void * pObj,

GOL_MSG * pMsg)

typedef struct {

OBJ_HEADER hdr;

SHORT textHeight;

DWORD Cvalue;

DWORD Pvalue;

BYTE NoOfDigits;

BYTE DotPos;

} DIGITALMETER;

WORD EbTranslateMsg(

void * pObj,

GOL_MSG * pMsg

)

typedef struct {

XCHAR * pTitle;

XCHAR * pSmplLabel;

XCHAR * pValLabel;

SHORT seriesCount;

WORD smplStart;

WORD smplEnd;

WORD valMax;

WORD valMin;

WORD perMax;

WORD perMin;

WORD * pColor;

void * pTitleFont;

void * pAxisLabelsFont;

void * pGridLabelsFont;

} CHARTPARAM;

typedef struct {

OBJ_HEADER hdr;

SHORT xCenter;

SHORT yCenter;

SHORT radius;

SHORT value;

WORD max;

WORD res;

SHORT curr_xPos;

SHORT curr_yPos;

SHORT new_xPos;

SHORT new_yPos;

SHORT vAngle;

} ROUNDDIAL;

typedef struct {

OBJ_HEADER hdr;

SHORT textHeight;

XCHAR * pBuffer;

WORD charMax;

WORD length;

} EDITBOX;

Microchip Graphics Library Quick Reference Guide
