10 Graphics Quick Reference Guide

Widget API

AnalogClock Button Chart Chart2 Chart3

Graphics Cong: USE_ANALOGCLOCK Graphics Cong:

USE_BUTTON

USE_BUTTON_MULTI_LINE

Graphics Cong: USE_CHART void ChHideSeries(

CHART *pObj,

WORD seriesNum)

XCHAR *ChGetSampleLabel(

CHART *pObj)

ANALOGCLOCK * AcCreate(

WORD ID,

SHORT left,

SHORT top,

SHORT right,

SHORT bottom,

SHORT hour,

SHORT minute,

SHORT radius,

BOOL sechand,

WORD state,

void * pBitmap,

GOL_SCHEME * pScheme)

BUTTON * BtnCreate(

WORD ID,

SHORT left,

SHORT top,

SHORT right,

SHORT bottom,

SHORT radius,

WORD state,

void * pBitmap,

XCHAR * pText,

GOL_SCHEME * pScheme)

CHART * ChCreate(

WORD ID,

SHORT left,

SHORT top,

SHORT right,

SHORT bottom,

WORD state,

DATASERIES * pData,

CHARTPARAM * pParam,

GOL_SCHEME * pScheme)

void ChGetShowSeriesCount(CHART * pObj) WORD ChGetSampleStart(

CHART *pObj)

WORD AcDraw(void * pObj) WORD BtnDraw(void * pObj) WORD ChDraw(void * pObj) WORD ChGetShowSeriesStatus(CHART * pObj) WORD ChGetSampleEnd(

CHART *pObj)

WORD AcHandsDraw(

ANALOGCLOCK * pObj,

SHORT hand,

SHORT thickness,

WORD color,

void * pBitmap)

XCHAR *BtnGetText(BUTTON *pObj) XCHAR *ChGetTitle(CHART *pObj) void ChSetValueLabel(

CHART* pObj, XCHAR* pValueLabel)

void ChSetPercentRange(

CHART * pObj,

WORD min,

WORD max)

void AcSetHour(

ANALOGCLOCK * pObj,

SHORT hour)

void BtnSetText(

BUTTON *pObj,

XCHAR *pString)

void ChSetTitle(

CHART *pObj,

XCHAR *pTitle)

XCHAR *ChGetValueLabel(

CHART* pObj)

WORD ChGetPercentRange(CHART *pObj)

void AcSetMinute(

ANALOGCLOCK * pObj,

SHORT minute)

void *BtnGetBitmap(BUTTON *pObj) void ChSetTitleFont(

CHART *pObj,

void *pFont)

WORD ChGetValueMax(CHART *pObj) void ChSetSampleRange(

CHART * pObj,

WORD start,

WORD end)

void AcSetSecond(

ANALOGCLOCK * pObj,

SHORT second)

void BtnSetBitmap(

BUTTON *pObj,

void *pBitmap)

XCHAR *ChGetTitleFont(CHART *pObj) WORD ChGetValueMin(CHART *pObj) WORD ChGetSampleRange(CHART *pObj)

typedef struct {

OBJ_HEADER hdr;

SHORT radius;

SHORT centerx;

SHORT centery;

SHORT valueS;

SHORT prev_valueS;

SHORT valueM;

SHORT prev_valueM;

SHORT valueH;

SHORT prev_valueH;

void * pBitmap;

} ANALOGCLOCK;

void BtnMsgDefault(

WORD translatedMsg,

void * pObj,

GOL_MSG * pMsg)

DATASERIES *ChAddDataSeries(

CHART *pObj,

WORD nSamples,

WORD *pData

XCHAR *pNames)

void ChSetValueRange(

CHART * pObj,

WORD min,

WORD max)

WORD ChGetPercentMax(CHART *pObj)

WORD BtnTranslateMsg(

void * pObj,

GOL_MSG * pMsg)

void ChRemoveDataSeries(

CHART * pObj,

WORD number)

WORD ChGetValueRange(CHART* pObj) WORD ChGetPercentMin(CHART *pObj)

typedef struct {

OBJ_HEADER hdr;

SHORT radius;

SHORT textWidth;

SHORT textHeight;

XCHAR * pText;

void * pBitmap;

} BUTTON;

void ChShowSeries(

CHART *pCh,

WORD seriesNum)

void ChSetSampleLabel(

CHART *pObj,

XCHAR *pXLabel)

void ChSetColorTable(

CHART* pObj,

GFX_COLOR *pColorArray)

Microchip Graphics Library Quick Reference Guide
