Curiosity Development Board User’s Guide
Tab le A -1 lists the parts that are not included with the Curiosity Development Board.
TABLE A-1: PARTS NOT INCLUDED WITH THE CURIOSITY DEVELOPMENT BOARD
Item
Manufacturing Part
Number
Manufacturer Digi-Key Part Number Description
J15 PJ-002BH-SMT CUI Inc. CP-002BHPJDTR-ND CONN POWER JACK
2.5X5.5 mm HI CUR
U5 LM340MP-5.0/NOPB TI LM340MP-5.0/NOPBTR-ND IC REG LDO 5V 1A
SOT223
J33, J34 PPTC081LFBN-RC Sullins Connector
Solutions
S7006-ND CONN HEADER
FEMALE 8POS .1" TIN
J7 PPTC061LFBN-RC Sullins Connector
Solutions
S7004-ND CONN HEADER
FEMALE 6POS .1" TIN
J8, J10, J14 PRPC008SAAN-RC Sullins Connector
Solutions
S1011EC-08-ND CONN HEADER .100"
SNGL STR 8POS
J13, J39, J40 PRPC004DAAN-RC Sullins Connector
Solutions
S2011EC-04-ND CONN HEADER .100"
DUAL STR 8POS
J3, J4, J5, J6 PREC002SAAN-RC Sullins Connector
Solutions
S1012EC-02-ND CONN HEADER .100"
SNGL STR 2POS
