Curiosity Development Board User’s Guide 2015 Microchip Technology Inc.
Note the following details of the code protection feature on Microchip devices: • Microchip products meet the specification contained in their particular Microchip Data Sheet. • Microchip believes that its family of products is one of the most secure families of its kind on the market today, when used in the intended manner and under normal conditions. • There are dishonest and possibly illegal methods used to breach the code protection feature.
CURIOSITY DEVELOPMENT BOARD USER’S GUIDE Table of Contents Preface ........................................................................................................................... 4 Introduction............................................................................................................ 4 Document Layout .................................................................................................. 4 Conventions Used in this Guide ................................................
CURIOSITY DEVELOPMENT BOARD USER’S GUIDE Preface NOTICE TO CUSTOMERS All documentation becomes dated, and this manual is no exception. Microchip tools and documentation are constantly evolving to meet customer needs, so some actual dialogs and/or tool descriptions may differ from those in this document. Please refer to our web site (www.microchip.com) to obtain the latest documentation available. Documents are identified with a “DS” number.
Preface CONVENTIONS USED IN THIS GUIDE This manual uses the following documentation conventions: DOCUMENT CONVENTIONS Description Represents Examples Arial font: Italic characters Referenced books MPLAB IDE User’s Guide Emphasized text ...is the only compiler...
Curiosity Development Board User’s Guide RECOMMENDED READING This user's guide describes how to use the Curiosity Development Board. For the latest information on using other tools, refer to the MPLAB® X IDE home page: www.microchip.com/mplabx/. This resource page contains updated documentation, downloads and links to other MPLAB X compatible tools, plug-ins and much more. THE MICROCHIP WEB SITE Microchip provides online support via our web site at www.microchip.com.
Preface CUSTOMER SUPPORT Users of Microchip products can receive assistance through several channels: • Distributor or Representative • Local Sales Office • Field Application Engineer (FAE) • Technical Support Customers should contact their distributor, representative or field application engineer (FAE) for support. Local sales offices are also available to help customers. Technical support is available through the web site at: www.microchip.com/support.
CURIOSITY DEVELOPMENT BOARD USER’S GUIDE Chapter 1. Introduction to Curiosity The Curiosity Development Board supports Microchip's 8-, 14- and 20-pin 8-bit PIC® MCUs. Dual-row expansion headers on either side of the socket offer flexibility of connectivity to all pins on the PIC MCUs. This board provides flexibility for experimentation through an application header with ground (GND) and supply voltage (VDD) connections.
Introduction to Curiosity 1.2 CURIOSITY DEVELOPMENT BOARD LAYOUT Figure 1-2 identifies the major features of the Curiosity Development Board. FIGURE 1-2: 1 CURIOSITY DEVELOPMENT BOARD LAYOUT 23 4 5 6 7 8 ™ mTouch® Button 13 1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. 12. 13. 2015 Microchip Technology Inc. 12 11 10 9 USB mini-B connector (on back) Footprint for 9V connector Master Clear Reset button 3.
Curiosity Development Board User’s Guide 1.3 POWER SOURCES The Curiosity Development Board can be powered in one of three ways, depending on its usage. 1.3.1 USB Connector (J2) The USB connector (J2) will power the entire Curiosity Development Board. A shunt jumper must be placed onto jumper J12 (Figure 1-2). The right two pins of J12 will connect +5V from the USB connector J2. The left two pins of J12 will connect +3.3V from the USB voltage regulator on the back side of the development board.
CURIOSITY DEVELOPMENT BOARD USER’S GUIDE Chapter 2. Getting Started The Curiosity Development Board must be used with MPLAB X Integrated Development Environment (IDE), available free on Microchip's web site, www.microchip.com. Use version v3.05 or later. The Curiosity Development Board, through MPLAB X, is a low-voltage in-circuit debugger, as well as a low-voltage programmer, for all supported devices.
Curiosity Development Board User’s Guide MPLAB X refers to the Curiosity Development Board as “Starter Kits (PKOB)”, with “Curiosity” listed below. Click on Curiosity, the correct device and XC8 compiler version being used, then click Apply (Figure 2-2). On the upper left hand corner of the Properties window, click on Starter Kit (PKOB) (Figure 2-3). The window will change to the Options for Starter Kit (PKOB) window (Figure 2-3).
Getting Started Note: When using the PKOB for programming, the Low Voltage Programming (LVP) bit of the Configuration Word(s) must be set (LVP = ON or '1'). Select options category “Program Options” and then “Enable Low Voltage Programming,” if it is not already selected. Click Apply, then OK (Figure 2-3). Once the project is finished, the microcontroller is ready to be programmed. Simply click on the Make and Program Device Main Project button and the device will be programmed (Figure 2-4).
CURIOSITY DEVELOPMENT BOARD USER’S GUIDE Chapter 3. Troubleshooting This chapter discusses common operational issues and how to resolve them. 3.1 THE DEMO APPLICATION DOES NOT RUN Curiosity Development Board must be plugged into a powered USB hub, computer, or other USB host device. To run the application, ensure the conditions listed below are met: 1. Start by plugging it into the USB device port, J2. LEDs D1 and D2 should light when VBUS is detected. 2.
VBUS DD+ ID GND J2 1 2 3 4 5 USB MINI-B Female 1 3 2 PJ-002BH-SMT DNP PGED PGEC GND NMCLR ICSP_VDD X2 X3 HDR-2.54 Male 1X6 STAGGERD 1 2 3 4 5 6 X4 TACT SPST X5 GND S2 RUBBER PAD 0.50x0.50x0.23 RUBBER PAD 0.50x0.50x0.23 RUBBER PAD 0.50x0.50x0.23 RUBBER PAD 0.50x0.50x0.23 X1 P1 DNP 2 VCMP VREF_2.5V D_VBUS 0.
Curiosity Development Board User’s Guide Table A-1 lists the parts that are not included with the Curiosity Development Board. TABLE A-1: Item PARTS NOT INCLUDED WITH THE CURIOSITY DEVELOPMENT BOARD Manufacturing Part Number Manufacturer CP-002BHPJDTR-ND Description J15 PJ-002BH-SMT U5 LM340MP-5.0/NOPB TI LM340MP-5.0/NOPBTR-ND IC REG LDO 5V 1A SOT223 J33, J34 PPTC081LFBN-RC Sullins Connector Solutions S7006-ND CONN HEADER FEMALE 8POS .
CURIOSITY DEVELOPMENT BOARD USER’S GUIDE Appendix B. General Notes B.1 POWER When the Curiosity board is USB-powered though a 5V supply rather than a USB port on a computer, MCLR is held in Reset for approximately five seconds. B.2 RN4020 BLUETOOTH® LOW ENERGY (BLE) MODULE 1. The RN4020 Bluetooth Low Energy (BLE) module must be configured before use.
