User manual

Board Technical Information
 2010 Microchip Technology Inc. DS51662C-page 41
TABLE A-16: PIC16F/LF1946/7 PIM AND ICE PIN/PORT COMPARISON
PIC16/LF1
946/7 PIM
Pin No.
PIC16F/LF
1946/7
Port
PIC16F/LF
1946/7 Pin
ICE Pin ICE Port
ICE
Pin
No.
PIC16F/LF
1946/7PIM
Pin No.
PIC16F/LF
1946/7
Port
PIC16F/LF
1946/7 Pin
ICE Pin ICE Port
ICE
Pin
No.
1 RE1 VLCD2 BIAS2 E1 14 33 C2 SEG13 SEG13 RC2 56
2 RE0 VLCD1 BIAS1 E0 15 34 C3 RC3 RC3 RC3 57
3
RG0 SEG42 SEG42 RH6 32 35 RE2 RC4 RC4 RC4 58
4
RG1 SEG43 SEG43 RH7 31 36 RC5 SEG12 SEG12 RC5 59
5
RG2 SEG44 SEG44 RJ3 13 37 RB7 RB7 RB7 RB7 60
6
RG3 SEG45 SEG45 RG5 20 38 VDD VDD ICEVDD ICEVDD 61
7RG5MCLR
ICEMCLR RG5 20 39 OSC1 OSC1 OSC1 RC1 62
8 RG4 SEG26 SEG26 RG4 21 40 RA6 OSC2 OSC2 RA6 63
9V
SS VSS VSS VSS 23 41 VSS VSS VSS VSS 65
10 V
DD VDD ICEVDD ICEVDD 24 42 RB6 RB6 RB6 RB6 66
11 RF7 SEG25 SEG25 RF7 25 43 RB5 RB5 RB5 RB5 67
12 RF6 SEG24 SEG24 RF6 26 44 RB4 SEG11 SEG11 RB4 68
13 RF5 SEG23 SEG23 RF5 27 45 RB3 SEG10 SEG10 RB3 69
14 RF4 SEG22 SEG22 RF4 28 46 RB2 SEG9 SEG9 RB2 70
15 RF3 SEG21 SEG21 RF3 29 47 RB1 SEG8 SEG8 RB1 71
16 RF2 SEG20 SEG20 RF2 30 48 RB0 RB0 RB0 RB0 72
17 RF1 SEG19 SEG19 RF1 35 49 RD7 SEG7 SEG7 RD7 77
18 RF0 SEG41 SEG41 RH5 33 50 RD6 SEG6 SEG6 RD6 78
19 V
DD VDD ICEVDD ICEVDD 37 51 RD5 SEG5 SEG5 RD5 79
20 V
SS VSS VSS VSS 38 52 RD4 SEG4 SEG4 RD4 80
21
RA3 SEG35 SEG35 RJ3 73 53 RD3 SEG3 SEG3 RD3 81
22
RA2 SEG34 SEG34 RJ2 74 54 RD2 SEG2 SEG2 RD2 82
23 RA1 AN1 AN1 RA1 41 55 RD1 SEG1 SEG1 RD1 83
24 RA0 AN0 AN0 RA0 42 56 V
SS VSS VSS VSS 84
25 V
SS VSS ICEVSS ICEVSS 44 57 VDD VDD VDD VDD 2
26 V
DD VDD ICDVDD ICDVDD 45 58 RD0 SEG0 SEG0 RD0 3
27 RA5 SEG15 SEG15 RA5 46 59 RE7 SEG31 SEG31 RE7 4
28 RA4 SEG14 SEG14 RA4 47 60 RE6 COM3 COM3 RE6 5
29 RC1 T1OSC1 T1OSC1 RC1 48 61 RE5 COM2 COM2 RE5 6
30 RC0 T1OSC0 T1OSC0 RC0 49 62 RE4 COM1 COM1 RE4 7
31 RC6 TX/CK TX/CK RC6 50 63 RE3 COM0 COM0 RE3 8
32 RC7 RX/DT RX/DT RC7 79 51 RE2 VLCD3 BIAS3 RE2 9
Legend: Unshaded cells indicate where a perfect match between PIM and ICE pins and ports exists.
Shaded cells indicate where differences between PIM and ICE ports and pins exist.
Bold text indicates the PIM pins that are not connected to any ICE pins or ports.
