PICDEM™ LCD 2 Demonstration Kit User’s Guide
DS51662C-page 40 2010 Microchip Technology Inc.
TABLE A-15: PIC16F946 PORT AND PIN COMPARISON
PIC16F946 Port PIC16F946 Pin ICE Pin ICE Port
RA0 AN0 AN0 RA0
RA1 AN1 AN1 RA1
RA6 T1OSCO T1OSCO RC0
RA7 T1OSCI T1OSCI RC1
RB0 RB0 RB0 RB0
RB5 COM1 COM1 RE4
RB6 RB6 RB6 RB6
RB7 RB7 RB7 RB7
RC0 VLCD1 BIAS1 RE0
RC1 VLCD2 BIAS2 RE1
RC3 RC3 RC3 RC3
RC4 RC4 RC4 RC4
RC6 TX/CK TX/CK RC6
RC7 RX/DT RX/DT RC7
Legend: Unshaded cells indicate a perfect match between the PIM and the glass.
Shaded cells indicate the pins that are remapped to the corresponding pin/port on the PIM.
