Board Technical Information
2010 Microchip Technology Inc. DS51662C-page 37
TABLE A-12: PIC18F8490 PIN AND PORT COMPARISON
PIC18F8490 Port PIC18F8490 Pin ICE Pin ICE Port
RA0 AN0 AN0 RA0
RA1 AN1 AN1 RA1
RA6OSC2OSC2RA6
RA7OSC1OSC1RA7
RB0 RB0 RB0 RB0
RB5 RB5 RB5 RB5
RB6 RB6 RB6 RB6
RB7 RB7 RB7 RB7
RC0 T1OSC1 T1OSC0 RC0
RC1 TIOSC0 TIOSC1 RC1
RC3 RC3 RC3 RC3
RC4 RC4 RC4 RC4
RC6 TX/CK TX/CK RC6
RC7 RX/DT RX/DT RC7
