PICDEM™ LCD 2 DEMONSTRATION
KIT USER’S GUIDE
2010 Microchip Technology Inc. DS51662C-page 23
Appendix A. Board Technical Information
The PICDEM™ LCD 2 hardware is not complicated and is intended to illustrate the
ease of use of various PIC
®
microcontrollers. The PICDEM LCD 2 features the follow-
ing hardware elements.
Note: Many of the following hardware sections will require specific demo board
jumper configurations. If a jumper is not listed in a particular section, then
that jumper has no effect on the circuitry within the hardware section you
are working. Figure A-1 shows a diagram of the PICDEM LCD 2 silkscreen
with all necessary jumpers highlighted in gray. Also, refer to the schematic
for circuit connections.
