PICDEM™ LCD 2 Demonstration Kit User’s Guide
DS51662C-page 22 2010 Microchip Technology Inc.
FIGURE 3-5: DEMO PROGRAM FLOWCHART
Increment Second Register
Clear Second
Is it 60?
Register,
Increment Minute
ISR
Register
Is it 60?
Clear Minute
Register,
Increment Hour
Register
Is it 24?
Clear Hour Register
Return
Yes
No
Yes
No
Yes
No
