Introduction
2010 Microchip Technology Inc. DS51662C-page 13
FIGURE 1-1: PICDEM™ LCD 2 HARDWARE
1.3 SAMPLE DEVICES
A PIM, populated with the PIC18F85J90, is included.
1.4 SAMPLE PROGRAMS
The PICDEM LCD 2 Demonstration Kit includes a CD-ROM with sample demonstration
programs. Depending on the device, these programs may be used with some of the
included sample devices with an In-Circuit Emulator (ICE) or with an In-Circuit
Debugger (ICD). For each type of device (PIC16F946, PIC16F917, PIC18F8490,
PIC18F85J90, PIC18F87J90 and PIC16F/LF1946/47), demo source code, several C
and/or .asm files and compiled code (one HEX file) are provided.
