Network Configuration

 2014 Microchip Technology Inc. Preliminary DS50002260B-page 25

Optional: Users can list all the preceding commands in the Wireless_Set-

ting.txt

file and copy all the commands to a serial terminal tool, Tera Term, to

configure the CY920 module in the WPAPSK Wi-Fi security mode, see

Example 3-3,

EXAMPLE 3-3: Wireless_Setting.txt FILE

cd cne

cd Application/NetIF

set mode wireless

cd /cne/Networking/DrvCfg/WlanCfg/Profile1

set SSID BCO-T1

set Security WPAWPA2PSK

cd WPAPSK

set Cipher AES

set Passphrase WelCome!23

sys reboot
