ATmega32A [DATASHEET]

Atmel-8155D-AVR-ATmega32A-Datasheet_02/2014

13.3.2 Alternate Functions of Port B

The Port B pins with alternate functions are shown in Table 12-6.

The alternate pin configuration is as follows:

• SCK – Port B, Bit 7

SCK: Master Clock output, Slave Clock input pin for SPI. When the SPI is enabled as a Slave, this pin is configured

as an input regardless of the setting of DDB7. When the SPI is enabled as a Master, the data direction of this pin is

controlled by DDB7. When the pin is forced by the SPI to be an input, the pull-up can still be controlled by the

PORTB7 bit.

• MISO – Port B, Bit 6

MISO: Master Data input, Slave Data output pin for SPI. When the SPI is enabled as a Master, this pin is config-

ured as an input regardless of the setting of DDB6. When the SPI is enabled as a Slave, the data direction of this

pin is controlled by DDB6. When the pin is forced by the SPI to be an input, the pull-up can still be controlled by the

PORTB6 bit.

• MOSI – Port B, Bit 5

MOSI: SPI Master Data output, Slave Data input for SPI. When the SPI is enabled as a Slave, this pin is configured

as an input regardless of the setting of DDB5. When the SPI is enabled as a Master, the data direction of this pin is

controlled by DDB5. When the pin is forced by the SPI to be an input, the pull-up can still be controlled by the

PORTB5 bit.

•SS

– Port B, Bit 4

: Slave Select input. When the SPI is enabled as a Slave, this pin is configured as an input regardless of the set-

ting of DDB4. As a Slave, the SPI is activated when this pin is driven low. When the SPI is enabled as a Master, the

data direction of this pin is controlled by DDB4. When the pin is forced by the SPI to be an input, the pull-up can still

be controlled by the PORTB4 bit.

• AIN1/OC0 – Port B, Bit 3

AIN1, Analog Comparator Negative Input. Configure the port pin as input with the internal pull-up switched off to

avoid the digital port function from interfering with the function of the analog comparator.

Table 13-6. Port B Pins Alternate Functions

Port Pin Alternate Functions

PB7 SCK (SPI Bus Serial Clock)

PB6 MISO (SPI Bus Master Input/Slave Output)

PB5 MOSI (SPI Bus Master Output/Slave Input)

PB4 SS

(SPI Slave Select Input)

PB3

AIN1 (Analog Comparator Negative Input)

OC0 (Timer/Counter0 Output Compare Match Output)

PB2

AIN0 (Analog Comparator Positive Input)

INT2 (External Interrupt 2 Input)

PB1 T1 (Timer/Counter1 External Counter Input)

PB0

T0 (Timer/Counter0 External Counter Input)

XCK (USART External Clock Input/Output)
