52
ATmega32A [DATASHEET]
Atmel-8155D-AVR-ATmega32A-Datasheet_02/2014
Note: 1. For the assembly program, two temporary registers are used to minimize the time from pull-ups are set on pins 0,
1, 6, and 7, until the direction bits are correctly set, defining bit 2 and 3 as low and redefining bits 0 and 1 as strong
high drivers.
13.2.3 Digital Input Enable and Sleep Modes
As shown in Figure 12-2, the digital input signal can be clamped to ground at the input of the schmitt-trigger. The
signal denoted SLEEP in the figure, is set by the MCU Sleep Controller in Power-down mode, Power-save mode,
Standby mode, and Extended Standby mode to avoid high power consumption if some input signals are left float-
ing, or have an analog signal level close to V
CC
/2.
SLEEP is overridden for port pins enabled as External Interrupt pins. If the External Interrupt Request is not
enabled, SLEEP is active also for these pins. SLEEP is also overridden by various other alternate functions as
described in “Alternate Port Functions” on page 55.
If a logic high level (“one”) is present on an Asynchronous External Interrupt pin configured as “Interrupt on Rising
Edge, Falling Edge, or Any Logic Change on Pin” while the External Interrupt is not enabled, the corresponding
External Interrupt Flag will be set when resuming from the above mentioned sleep modes, as the clamping in these
sleep modes produces the requested logic change.
13.2.4 Unconnected pins
If some pins are unused, it is recommended to ensure that these pins have a defined level. Even though most of
the digital inputs are disabled in the deep sleep modes as described above, floating inputs should be avoided to
Assembly Code Example
(1)
:.
; Define pull-ups and set outputs high
; Define directions for port pins
ldi r16,(1<<PB7)|(1<<PB6)|(1<<PB1)|(1<<PB0)
ldi r17,(1<<DDB3)|(1<<DDB2)|(1<<DDB1)|(1<<DDB0)
out PORTB,r16
out DDRB,r17
; Insert nop for synchronization
nop
; Read port pins
in r16,PINB
:.
C Code Example
(1)
unsigned char i;
:.
/* Define pull-ups and set outputs high */
/* Define directions for port pins */
PORTB = (1<<PB7)|(1<<PB6)|(1<<PB1)|(1<<PB0);
DDRB = (1<<DDB3)|(1<<DDB2)|(1<<DDB1)|(1<<DDB0);
/* Insert nop for synchronization*/
_NOP();
/* Read port pins */
i = PINB;
:.
