ATmega32A [DATASHEET]

Atmel-8155D-AVR-ATmega32A-Datasheet_02/2014

The details on programming through the JTAG interface and programming specific JTAG instructions are given in

the section “Programming via the JTAG Interface” on page 284.

24.9 Register Description

24.9.1 OCDR – On-chip Debug Register

The OCDR Register provides a communication channel from the running program in the microcontroller to the

debugger. The CPU can transfer a byte to the debugger by writing to this location. At the same time, an Internal

Flag; I/O Debug Register Dirty – IDRD – is set to indicate to the debugger that the register has been written. When

the CPU reads the OCDR Register the 7 LSB will be from the OCDR Register, while the MSB is the IDRD bit. The

debugger clears the IDRD bit when it has read the information.

In some AVR devices, this register is shared with a standard I/O location. In this case, the OCDR Register can only

be accessed if the OCDEN Fuse is programmed, and the debugger enables access to the OCDR Register. In all

other cases, the standard I/O location is accessed.

Refer to the debugger documentation for further information on how to use this register.

24.10 Bibliography

For more information about general Boundary-scan, the following literature can be consulted:

• IEEE: IEEE Std 1149.1-1990. IEEE Standard Test Access Port and Boundary-scan Architecture, IEEE, 1993

• Colin Maunder: The Board Designers Guide to Testable Logic Circuits, Addison-Wesley, 1992

Bit 7 6543210

MSB/IDRD LSB OCDR

Read/Write R/W R/W R/W R/W R/W R/W R/W R/W

Initial Value 0 0000000
