generated baud rate of the receiver does not have a similar (see Table 19-2) base frequency, the receiver will not

be able to synchronize the frames to the start bit.

The following equations can be used to calculate the ratio of the incoming data rate and internal receiver baud rate.

D Sum of character size and parity size (D = 5 to 10 bit)

S Samples per bit. S = 16 for Normal Speed mode and S = 8 for

Double Speed mode.

First sample number used for majority voting. S

= 8 for Normal Speed and

= 4 for Double Speed mode.

Middle sample number used for majority voting. S

= 9 for Normal Speed and

= 5 for Double Speed mode.

slow

is the ratio of the slowest incoming data rate that can be accepted in relation to the

receiver baud rate. R

fast

is the ratio of the fastest incoming data rate that can be

accepted in relation to the receiver baud rate.

Table 19-2 and Table 19-3 list the maximum receiver baud rate error that can be tolerated. Note that Normal

Speed mode has higher toleration of baud rate variations.

Table 20-2. Recommended Maximum Receiver Baud Rate Error for Normal Speed Mode (U2X = 0)

# (Data+Parity Bit) R

slow

(%) R

fast

(%)

Max Total Error

(%)

Recommended Max Receiver

Error (%)

5 93.20 106.67 +6.67/-6.8 ±3.0

6 94.12 105.79 +5.79/-5.88 ±2.5

7 94.81 105.11 +5.11/-5.19 ±2.0

8 95.36 104.58 +4.58/-4.54 ±2.0

9 95.81 104.14 +4.14/-4.19 ±1.5

10 96.17 103.78 +3.78/-3.83 ±1.5

Table 20-3. Recommended Maximum Receiver Baud Rate Error for Double Speed Mode (U2X = 1)

# (Data+Parity Bit) R

slow

(%) R

fast

(%)

Max Total Error

(%)

Recommended Max Receiver

Error (%)

5 94.12 105.66 +5.66/-5.88 ±2.5

6 94.92 104.92 +4.92/-5.08 ±2.0

7 95.52 104.35 +4.35/-4.48 ±1.5

8 96.00 103.90 +3.90/-4.00 ±1.5

9 96.39 103.53 +3.53/-3.61 ±1.5

10 96.70 103.23 +3.23/-3.30 ±1.0

slow

D 1+S

S 1– DS S

-------------------------------------------=

fast

D 2+S

D 1+SS

-----------------------------------=
