ATmega32A [DATASHEET]

Atmel-8155D-AVR-ATmega32A-Datasheet_02/2014

• Bit 6, 3 – WGM2[1:0]: Waveform Generation Mode

These bits control the counting sequence of the counter, the source for the maximum (TOP) counter value, and

what type of waveform generation to be used. Modes of operation supported by the Timer/Counter unit are: Normal

mode, Clear Timer on Compare match (CTC) mode, and two types of Pulse Width Modulation (PWM) modes. See

Table 17-2 and “Modes of Operation” on page 124.

Note: 1. The CTC2 and PWM2 bit definition names are now obsolete. Use the WGM21:0 definitions. However, the function-

ality and location of these bits are compatible with previous versions of the timer.

• Bit 5:4 – COM2[1:0]: Compare Match Output Mode

These bits control the Output Compare pin (OC2) behavior. If one or both of the COM21:0 bits are set, the OC2

output overrides the normal port functionality of the I/O pin it is connected to. However, note that the Data Direction

When OC2 is connected to the pin, the function of the COM21:0 bits depends on the WGM21:0 bit setting. Table

17-3 shows the COM21:0 bit functionality when the WGM21:0 bits are set to a normal or CTC mode (non-PWM).

Table 17-4 shows the COM2[1:0] bit functionality when the WGM21:0 bits are set to fast PWM mode.

Note: 1. A special case occurs when OCR2 equals TOP and COM21 is set. In this case, the compare match is ignored, but

the set or clear is done at TOP. See “Fast PWM Mode” on page 125 for more details.

Table 17-5 shows the COM2[1:0] bit functionality when the WGM21:0 bits are set to phase correct PWM mode

Table 18-2. Waveform Generation Mode Bit Description

(1)

Mode

WGM21

(CTC2)

WGM20

(PWM2)

Timer/Counter Mode of

Operation TOP

Update of

OCR2

TOV2 Flag

Set on

0 0 0 Normal 0xFF Immediate MAX

1 0 1 PWM, Phase Correct 0xFF TOP BOTTOM

2 1 0 CTC OCR2 Immediate MAX

3 1 1 Fast PWM 0xFF BOTTOM MAX

Table 18-3. Compare Output Mode, non-PWM Mode

COM21 COM20 Description

0 0 Normal port operation, OC2 disconnected.

0 1 Toggle OC2 on compare match

1 0 Clear OC2 on compare match

1 1 Set OC2 on compare match

Table 18-4. Compare Output Mode, Fast PWM Mode

(1)

COM21 COM20 Description

0 0 Normal port operation, OC2 disconnected.

01Reserved

1 0 Clear OC2 on compare match, set OC2 at BOTTOM,

(non-inverting mode)

1 1 Set OC2 on compare match, clear OC2 at BOTTOM,

(inverting mode)
