246

ATmega32A [DATASHEET]

Atmel-8155D-AVR-ATmega32A-Datasheet_02/2014

Note: 1. For details about these two section, see “NRWW – No Read-While-Write Section” on page 253 and “RWW – Read-

While-Write Section” on page 253

Note: 1. Z15: always ignored

Z0: should be zero for all SPM commands, byte select for the LPM instruction.

See “Addressing the Flash during Self-Programming” on page 257 for details about the use of Z-pointer during

Self-Programming.

26.9 Register Description

26.9.1 SPMCR – Store Program Memory Control Register

The Store Program Memory Control Register contains the control bits needed to control the Boot Loader

operations.

• Bit 7 – SPMIE: SPM Interrupt Enable

When the SPMIE bit is written to one, and the I-bit in the Status Register is set (one), the SPM ready interrupt will

be enabled. The SPM ready Interrupt will be executed as long as the SPMEN bit in the SPMCR Register is cleared.

• Bit 6 – RWWSB: Read-While-Write Section Busy

When a self-programming (Page Erase or Page Write) operation to the RWW section is initiated, the RWWSB will

be set (one) by hardware. When the RWWSB bit is set, the RWW section cannot be accessed. The RWWSB bit

will be cleared if the RWWSRE bit is written to one after a Self-Programming operation is completed. Alternatively

the RWWSB bit will automatically be cleared if a page load operation is initiated.

• Bit 5 – Reserved Bit

This bit is a reserved bit in the ATmega32A and always read as zero.

• Bit 4 – RWWSRE: Read-While-Write Section Read Enable

Table 26-8. Explanation of Different Variables used in Figure 25-3 and the Mapping to the Z-pointer

Variable

Corresponding

Z-value

(1)

Description

PCMSB

13 Most significant bit in the Program Counter. (The

Program Counter is 14 bits PC[13:0])

PAGEMS B

5 Most significant bit which is used to address the

words within one page (64 words in a page requires

6 bits PC [5:0]).

ZPCMSB

Z14 Bit in Z-register that is mapped to PCMSB. Because

Z0 is not used, the ZPCMSB equals PCMSB + 1.

ZPAGEMSB

Z6 Bit in Z-register that is mapped to PAGEMSB.

Because Z0 is not used, the ZPAGEMSB equals

PAGEMSB + 1.

PCPAGE

PC[13:6] Z14:Z7 Program Counter page address: Page select, for

page erase and page write

PCWORD

PC[5:0] Z6:Z1 Program Counter word address: Word select, for

filling temporary buffer (must be zero during page

write operation)

Bit 765 4 3210

SPMIE RWWSB – RWWSRE BLBSET PGWRT PGERS SPMEN SPMCR

Read/Write R/W R R R/W R/W R/W R/W R/W

Initial value 0 0 0 0 0 0 0 0
