ATmega32A [DATASHEET]

Atmel-8155D-AVR-ATmega32A-Datasheet_02/2014

23.9.2 ADCSRA – ADC Control and Status Register A

• Bit 7 – ADEN: ADC Enable

Writing this bit to one enables the ADC. By writing it to zero, the ADC is turned off. Turning the ADC off while a con-

version is in progress, will terminate this conversion.

• Bit 6 – ADSC: ADC Start Conversion

In Single Conversion mode, write this bit to one to start each conversion. In Free Running Mode, write this bit to

one to start the first conversion. The first conversion after ADSC has been written after the ADC has been enabled,

or if ADSC is written at the same time as the ADC is enabled, will take 25 ADC clock cycles instead of the normal

13. This first conversion performs initialization of the ADC.

ADSC will read as one as long as a conversion is in progress. When the conversion is complete, it returns to zero.

Writing zero to this bit has no effect.

01100 ADC2 ADC2 10x

01101

ADC3 ADC2 10x

01110

ADC2 ADC2 200x

01111

ADC3 ADC2 200x

10000

ADC0 ADC1 1x

10001

ADC1 ADC1 1x

10010

N/A ADC2 ADC1 1x

10011

ADC3 ADC1 1x

10100

ADC4 ADC1 1x

10101

ADC5 ADC1 1x

10110

ADC6 ADC1 1x

10111

ADC7 ADC1 1x

11000

ADC0 ADC2 1x

11001

ADC1 ADC2 1x

11010

ADC2 ADC2 1x

11011

ADC3 ADC2 1x

11100

ADC4 ADC2 1x

11101 ADC5 ADC2 1x

11110 1.22V (V

) N/A

11111 0V (GND)

Table 23-4. Input Channel and Gain Selections (Continued)

MUX4:0

Single Ended

Input

Positive Differential

Input

Negative Differential

Input Gain

Bit 76543210

ADEN ADSC ADATE ADIF ADIE ADPS2 ADPS1 ADPS0 ADCSRA

Read/Write R/W R/W R/W R/W R/W R/W R/W R/W

Initial Value00000000
