44.6.4.15 24 bpp Packed Memory Mapping, RGB 8:8:8
44.6.4.16 25 bpp Memory Mapping, ARGB 1:8:8:8
44.6.4.17 32 bpp Memory Mapping, ARGB 8:8:8:8
44.6.4.18 32 bpp Memory Mapping, RGBA 8:8:8:8
Table 44-25. 24 bpp packed memory mapping, little endian organization at address 0x0, 0x1, 0x2, 0x3
Mem addr 0x3 0x2 0x1 0x0
Bit 313029282726252423222120191817161514131211109876543210
Pixel 24 bpp B1[7:0] R0[7:0] G0[7:0] B0[7:0]
Table 44-26. 24 bpp packed memory mapping, little endian organization at address 0x4, 0x5, 0x6, 0x7
Mem addr 0x7 0x6 0x5 0x4
Bit 313029282726252423222120191817161514131211109876543210
Pixel 24 bpp G2[7:0] B2[7:0] R1[7:0] G1[7:0]
Table 44-27. 25 bpp memory mapping, little endian organization
Mem addr 0x3 0x2 0x1 0x0
Bit 313029282726252423222120191817161514131211109876543210
Pixel 25 bpp A0 R0[7:0] G0[7:0] B0[7:0]
Table 44-28. 32 bpp memory mapping, little endian organization
Mem addr 0x3 0x2 0x1 0x0
Bit 313029282726252423222120191817161514131211109 8 7 6 5 4 3 2 1 0
Pixel 32 bpp A0[7:0] R0[7:0] G0[7:0] B0[7:0]
Table 44-29. 32 bpp memory mapping, little endian organization
Mem addr 0x3 0x2 0x1 0x0
Bit 313029282726252423222120191817161514131211109876543210
Pixel 32 bpp R0[7:0] G0[7:0] B0[7:0] A0[7:0]
