44.6.4.12 19 bpp Unpacked Memory Mapping with Transparency Bit, RGB 1:6:6:6
44.6.4.13 19 bpp Packed Memory Mapping with Transparency Bit, ARGB 1:6:6:6
44.6.4.14 24 bpp Unpacked Memory Mapping, RGB 8:8:8
Table 44-18. 18 bpp packed memory mapping, little endian organization at address 0x4, 0x5, 0x6, 0x7
Mem addr 0x7 0x6 0x5 0x4
Bit 313029282726252423222120191817161514131211109876543210
Pixel 18 bpp R2[3:0] G2[5:0] B2[5:0] R1[5:2] G1[5:2]
Table 44-19. 18 bpp packed memory mapping, little endian organization at address 0x8, 0x9, 0xA, 0xB
Mem addr 0xB 0xA 0x9 0x8
Bit 313029282726252423222120191817161514131211109 8 7 6 5 4 3 2 1 0
Pixel 18 bpp G4[1:0] B4[5:0] R3[5:0] G3[5:0] B3[3:0] R2[5:4]
Table 44-20. 19 bpp unpacked memory mapping, little endian organization
Mem addr 0x3 0x2 0x1 0x0
Bit 313029282726252423222120191817161514131211109876543210
Pixel 19 bpp A0 R0[5:0] G0[5:0] B0[5:0]
Table 44-21. 19 bpp packed memory mapping, little endian organization at address 0x0, 0x1, 0x2, 0x3
Mem addr 0x3 0x2 0x1 0x0
Bit 313029282726252423222120191817161514131211109876543210
Pixel 19 bpp G1[1:0] B1[5:0] A0 R0[5:0] G0[5:0] B0[5:0]
Table 44-22. 19 bpp packed memory mapping, little endian organization at address 0x4, 0x5, 0x6, 0x7
Mem addr 0x7 0x6 0x5 0x4
Bit 313029282726252423222120191817161514131211109876543210
Pixel 19 bpp R2[3:0] G2[5:0] B2[5:0] A1 R1[5:2] G1[5:2]
Table 44-23. 19 bpp packed memory mapping, little endian organization at address 0x8, 0x9, 0xA, 0xB
Mem addr 0xB 0xA 0x9 0x8
Bit 313029282726252423222120191817161514131211109876543210
Pixel 19 bpp G4[1:0] B4[5:0] A3 R3[5:0] G3[5:0] B3[3:0] R2[5:4]
Table 44-24. 24 bpp memory mapping, little endian organization
Mem addr 0x3 0x2 0x1 0x0
Bit 313029282726252423222120191817161514131211109876543210
Pixel 24 bpp R0[7:0] G0[7:0] B0[7:0]
