SAM9N12/SAM9CN11/SAM9CN12 [DATASHEET]
11063K–ATARM–05-Nov-13
40.8.28 USART LIN Baud Rate Register
Name: US_LINBRR
Addresses: 0xF801C05C (0), 0xF802005C (1), 0xF802405C (2), 0xF802805C (3)
Access: Read-only
This register is relevant only if USART_MODE = 0xA or 0xB in “USART Mode Register” .
Returns the baud rate value after the synchronization process completion.
LINCD: Clock Divider after Synchronization
LINFP: Fractional Part after Synchronization
31 30 29 28 27 26 25 24
––––––––
23 22 21 20 19 18 17 16
––––– LINFP
15 14 13 12 11 10 9 8
LINCD
76543210
LINCD
