SAM9N12/SAM9CN11/SAM9CN12 [DATASHEET]
11063K–ATARM–05-Nov-13
40.8.27 USART LIN Identifier Register
Name: US_LINIR
Addresses: 0xF801C058 (0), 0xF8020058 (1), 0xF8024058 (2), 0xF8028058 (3)
Access: Read-write or Read-only
This register is relevant only if USART_MODE = 0xA or 0xB in “USART Mode Register” .
IDCHR: Identifier Character
If USART_MODE = 0xA (Master node configuration):
IDCHR is Read-write and its value is the Identifier character to be transmitted.
If USART_MODE = 0xB (Slave node configuration):
IDCHR is Read-only and its value is the last Identifier character that has been received.
31 30 29 28 27 26 25 24
––––––––
23 22 21 20 19 18 17 16
––––––––
15 14 13 12 11 10 9 8
––––––––
76543210
IDCHR
