Baud Rate Calculation Example
Table 40-4 shows calculations of CD to obtain a baud rate at 38,400 bit/s for different source clock frequencies. This
table also shows the actual resulting baud rate and the error.
The baud rate is calculated with the following formula:
The baud rate error is calculated with the following formula. It is not recommended to work with an error higher than 5%.
40.7.1.2 Fractional Baud Rate in Asynchronous Mode
The Baud Rate generator previously defined is subject to the following limitation: the output frequency changes by only
integer multiples of the reference frequency. An approach to this problem is to integrate a fractional N clock generator
that has a high resolution. The generator architecture is modified to obtain baud rate changes by a fraction of the
reference source clock. This fractional part is programmed with the FP field in the US_BRGR. If FP is not 0, the fractional
part is activated. The resolution is one eighth of the clock divider. This feature is only available when using USART
normal mode. The fractional baud rate is calculated using the following formula:
Table 40-4. Baud Rate Example (OVER = 0)
Source Clock
(MHz)
Expected Baud Rate
(Bit/s) Calculation Result CD
Actual Baud Rate
(Bit/s) Error
3,686,400 38,400 6.00 6 38,400.00 0.00%
4,915,200 38,400 8.00 8 38,400.00 0.00%
5,000,000 38,400 8.14 8 39,062.50 1.70%
7,372,800 38,400 12.00 12 38,400.00 0.00%
8,000,000 38,400 13.02 13 38,461.54 0.16%
12,000,000 38,400 19.53 20 37,500.00 2.40%
12,288,000 38,400 20.00 20 38,400.00 0.00%
14,318,180 38,400 23.30 23 38,908.10 1.31%
14,745,600 38,400 24.00 24 38,400.00 0.00%
18,432,000 38,400 30.00 30 38,400.00 0.00%
24,000,000 38,400 39.06 39 38,461.54 0.16%
24,576,000 38,400 40.00 40 38,400.00 0.00%
25,000,000 38,400 40.69 40 38,109.76 0.76%
32,000,000 38,400 52.08 52 38,461.54 0.16%
32,768,000 38,400 53.33 53 38,641.51 0.63%
33,000,000 38,400 53.71 54 38,194.44 0.54%
40,000,000 38,400 65.10 65 38,461.54 0.16%
50,000,000 38,400 81.38 81 38,580.25 0.47%
BaudRate MCK CD 16×⁄=
Error 1
ExpectedBaudRate
ActualBaudRate
-------------------------------------------------- -


–=
Baudrate
SelectedClock
82 Over–()CD
FP
8
-------+




-----------------------------------------------------------------=
