33.7.10 UDP Endpoint Control and Status Register (Control, Bulk Interrupt Endpoints)
Name: UDP_CSRx [x = 0..5]
Address: 0xF803C030
Access: Read-write
WARNING: Due to synchronization between MCK and UDPCK, the software application must wait for the end of the write opera-
tion before executing another write by polling the bits which must be set/cleared.
#if defined ( __ICCARM__ )
#define nop() (__no_operation())
#elif defined ( __GNUC__ )
#define nop() __asm__ __volatile__ ( "nop" )
#endif
/// Bitmap for all status bits in CSR that are not effected by a value 1.
#define REG_NO_EFFECT_1_ALL AT91C_UDP_RX_DATA_BK0\
| AT91C_UDP_RX_DATA_BK1\
| AT91C_UDP_STALLSENT\
| AT91C_UDP_RXSETUP\
| AT91C_UDP_TXCOMP
/// Sets the specified bit(s) in the UDP_CSR register.
/// \param endpoint The endpoint number of the CSR to process.
/// \param flags The bitmap to set to 1.
#define SET_CSR(endpoint, flags) \
{ \
volatile unsigned int reg; \
reg = AT91C_BASE_UDP->UDP_CSR[endpoint] ; \
reg |= REG_NO_EFFECT_1_ALL; \
reg |= (flags); \
AT91C_BASE_UDP->UDP_CSR[endpoint] = reg; \
for( nop_count=0; nop_count<15; nop_count++ ) {\
nop();\
}\
}
31 30 29 28 27 26 25 24
––––– RXBYTECNT
23 22 21 20 19 18 17 16
RXBYTECNT
15 14 13 12 11 10 9 8
EPEDS – – – DTGLE EPTYPE
76543210
DIR RX_DATA_BK1 FORCESTALL TXPKTRDY STALLSENT RXSETUP
RX_DATA_
BK0
TXCOMP
