31.7.7 DDRSDRC Low-power Register
Name: DDRSDRC_LPR
Address: 0xFFFFE81C
Access: Read-write
Reset: See Table 31-16
• LPCB: Low-power Command Bit
Reset value is 0.
• CLK_FR: Clock Frozen Command Bit
Reset value is “0”.
This field sets the clock low during power-down mode or during deep power-down mode. Some SDRAM devices do not support
freezing the clock during power-down mode or during deep power-down mode. Refer to the SDRAM device datasheet for details
on this.
0: Clock(s) is/are not frozen.
1: Clock(s) is/are frozen.
• PASR: Partial Array Self Refresh
Reset value is “0”.
This field is unique to Low-power SDRAM. It is used to specify whether only one quarter, one half or all banks of the SDRAM
array are enabled. Disabled banks are not refreshed in self-refresh mode.
The values of this field are dependant on Low-power SDRAM devices.
31 30 29 28 27 26 25 24
–– ––––––
23 22 21 20 19 18 17 16
– – UPD_MR – – – APDE
15 14 13 12 11 10 9 8
–– TIMEOUT – DS
76543210
– PASR CLK_FR LPCB
Value Name Description
0 NOLOWPOWER
Low-power feature is inhibited: no power-down, self-refresh and deep power mode are
issued to the SDRAM device.
1 SELFREFRESH
The DDRSDRC issues a Self Refresh Command to the SDRAM device, the clock(s)
is/are de-activated and the CKE signal is set low. The SDRAM device leaves the self-
refresh mode when accessed and enters it after the access.
2POWERDOWN
The DDRSDRC issues a Power-down Command to the SDRAM device after each
access, the CKE signal is set low. The SDRAM device leaves the power-down
mode when accessed and enters it after the access.
3 DEEPPOWERDOWN
The DDRSDRC issues a Deep Power-down Command to the Low-power SDRAM
device.
Note: This mode is unique to Low-power SDRAM devices.
