31.7.3 DDRSDRC Configuration Register
Name: DDRSDRC_CR
Address: 0xFFFFE808
Access: Read-write
Reset: See Table 31-16
This register can only be written if the if the WPEN bit is cleared in “DDRSDRC Write Protect Mode Register” .
• NC: Number of Column Bits
The reset value is 9 column bits.
SDR-SDRAM devices with eight columns in 16-bit mode are not supported.
• NR: Number of Row Bits
The reset value is 12 row bits.
31 30 29 28 27 26 25 24
––––––––
23 22 21 20 19 18 17 16
– DECOD – NB – ACTBST – EBISHARE
15 14 13 12 11 10 9 8
– OCD – – DIS_DLL DIC
76543210
DLL CAS NR NC
Value Name Description
0 DDR9_SDR8 9-bit for DDR, 8-bit for SDR
1 DDR10_SDR9 10-bit for DDR, 9-bit for SDR
2 DDR11_SDR10 11-bit for DDR, 10-bit for SDR
3 DDR12_SDR11 12-bit for DDR, 11-bit for SDR
Value Name description
0 11_BIT 11 row bit
1 12_BIT 12 row bit
2 13_BIT 13 row bit
3 14_BIT 14 row bit
