8.3 Peripheral Interrupts and Clock Control
8.3.1 System Interrupt
The System Interrupt in Source 1 is the wired-OR of the interrupt signals coming from:
 the DDR2/LPDDR Controller
 the Debug Unit
 the Periodic Interval Timer
 the Real-Time Clock
 the Watchdog Timer
 the Reset Controller
 the Power Management Controller
The clock of these peripherals cannot be deactivated and Peripheral ID 1 can only be used within the Advanced Interrupt
Controller.
8.3.2 External Interrupts
All external interrupt signals, i.e., the Fast Interrupt signal FIQ or the Interrupt signal IRQ, use a dedicated Peripheral ID.
However, there is no clock control associated with these peripheral IDs.
8.4 Peripheral Signal Multiplexing on I/O Lines
The SAM9N12/CN11/CN12 features 4 PIO controllers, PIOA, PIOB, PIOC and PIOD, which multiplex the I/O lines of the
peripheral set.
Each PIO Controller controls 32 lines, 19 lines, 32 lines and 22 lines respectively for PIOA, PIOB, PIOC and PIOD. Each
line can be assigned to one of three peripheral functions, A, B or C.
Refer to Section 4. “Package and Pinout” and the package pinout tables, Table 4-1, Table 4-2, depending on the
package.
8.4.1 Reset State
The column “Reset State” (Table 4-1, Table 4-2) indicates the reset state of the line with mnemonics.
 “PIO”/”signal”
Indicates whether the PIO Line resets in I/O mode or in peripheral mode. If “PIO” is mentioned, the PIO Line is
maintained in a static state as soon as the reset is released. As a result, the bit corresponding to the PIO Line in the
register PIO_PSR (Peripheral Status Register) resets low.
If a signal name is mentioned in the “Reset State” column, the PIO Line is assigned to this function and the
corresponding bit in PIO_PSR resets high. This is the case on pins controlling memories, in particular the address lines,
which require the pin to be driven as soon as the reset is released.
26 Reserved
27 SHA Secure Hash Algorithm
28 SSC Synchronous Serial Controller
29 AES Advanced Encryption Standard
30 TRNG True Random Number Generator
31 AIC Advanced Interrupt Controller IRQ
Table 8-1. SAM9N12/CN11/CN12 Peripheral Identifiers (Continued)
Instance ID Instance name Instance description External interrupt Wired-or interrupt
