22.12.13 PMC Programmable Clock Register
Name: PMC_PCKx
Address: 0xFFFFFC40
Access: Read-write
• CSS: Master Clock Source Selection
•PRES: Programmable Clock Prescaler
31 30 29 28 27 26 25 24
––––––––
23 22 21 20 19 18 17 16
––––––––
15 14 13 12 11 10 9 8
––––––––
76543210
–PRES– CSS
Value name Description
0 SLOW_CLK Slow Clock is selected
1 MAIN_CLK Main Clock is selected
2 PLLA_CLK PLLACK/PLLADIV2 is selected
3 PLLB_CLK PLLBCK is selected
4 MCK_CLK Master Clock is selected
Value name Description
0 CLOCK_DIV1 Selected clock
1 CLOCK_DIV2 Selected clock divided by 2
2 CLOCK_DIV4 Selected clock divided by 4
3 CLOCK_DIV8 Selected clock divided by 8
4 CLOCK_DIV16 Selected clock divided by 16
5 CLOCK_DIV32 Selected clock divided by 32
6 CLOCK_DIV64 Selected clock divided by 64
7 Reserved Reserved
