22.12.3 PMC System Clock Status Register
Name: PMC_SCSR
Address: 0xFFFFFC08
Access: Read-only
•PCK: Processor Clock Status
0: The Processor clock is disabled.
1: The Processor clock is enabled.
• DDRCK: DDR Clock Status
0: The DDR clock is disabled.
1: The DDR clock is enabled.
• LCDCK: LCD Clock Status
0: The LCD clock is disabled.
1: The LCD clock is enabled.
• UHP: USB Hos t Port Clock Status
0: The UHP48M and UHP12M OHCI clocks are disabled.
1: The UHP48M and UHP12M OHCI clocks are enabled.
• UDP: USB Device Port Clock Status
0: The USB Device clock is disabled.
1: The USB Device clock is enabled.
•PCKx: Programmable Clock x Output Status
0: The corresponding Programmable Clock output is disabled.
1: The corresponding Programmable Clock output is enabled.
31 30 29 28 27 26 25 24
––––––––
23 22 21 20 19 18 17 16
––––––––
15 14 13 12 11 10 9 8
––––––PCK1PCK0
76543210
UDP UHP – – LCDCK DDRCK – PCK
