SAM9N12/SAM9CN11/SAM9CN12 [DATASHEET]
11063K–ATARM–05-Nov-13
UDP:
Section 33.4 “Product Dependencies”, second paragraph removed.
Section 33.5 “Typical Connection”, revised schematic and VBUS Monitoring.
Section 33.6.3.2 “Entering Attached State”, revised, replaced paragraphs before Warning.
Section 33.7.12 “UDP Transceiver Control Register”, bit field 9 is dedicated to PUON.
7322
UHP:
Section 34-1 “Block Diagram”, removed Warning.
Section 34.6 “Typical Connection”, revised schematic and text.
7322
USART:
Melange of references to PDC/DMA removed in favor of DMA implementation. 7284
UART:
Section 41-1 “UART Functional Block Diagram”, revised. 7285
Electrical Characteristics:
Table 48-7, “Main Oscillator Characteristics”, revised schematic in note below table.
Table 48-11, “32 kHz Oscillator Characteristics”, revised schematic in note below table.
7304
Table 48-5, “Processor Clock Waveform Parameters”, updated.
Table 48-6, “System Clock Waveform Parameters”, replaces “Master Clock Waveform Parameters”.
Section 48.13 “SMC Timings”, added to datasheet.
Section 48.14 “DDRSDRC Timings”, added to datasheet.
Section 48.15 “Peripheral Timings”, added to datasheet.
7334
Table 48-2, “DC Characteristics”
Table 48-3, “Power Consumption for Different Modes”
Table 48-4, “Power Consumption by Peripheral in Active Mode”
Table 48-17, “I/O Characteristics”
former TBDs assigned values
rfo
Doc. Rev
11063B
Comments Change
Request
Ref.
Table 4-2, “BGA247 Pin Description” updated. 7271
Doc. Rev
11063A
Comments Change
Request
Ref.
First issue
Doc. Rev
11063C
Comments (Continued) Change
Request
Ref.
