SAM9N12/SAM9CN11/SAM9CN12 [DATASHEET]
11063K–ATARM–05-Nov-13
Revision History
In the tables that follow, the most recent version of the document appears first.
“rfo” indicates changes requested during document review and approval loop.
Doc
Revision
11063K
Comments
Change
Request
Ref.
Section 51. ”SAM9N/CN Series Errata”
Section 51.3 ”SAM9CN12 Errata: Revision B”: Section 51.3.1.1 ”Boot from SPI Data/Serial Flash Devices do
not work with All Memories”: Corrected data/serial Flash reference from AT25DF012 to AT25DF021
Deleted Section 51.3.2 ”16 MHz Main Crystal” from Section 51.3 ”SAM9CN12 Errata: Revision B”.
9429
9429
Doc. Rev
11063J
Comments Change
Request
Ref.
Introduction:
“Description”, revised content and presentation.
Section 1. “Features”:
- added a list on safety features
- moved SHA references to “Safety” list
Section 3. “Signal Description”, removed references to VBG pins in Table 3-1, “Signal Description List” and
Table 3-2, “SAM9N12/CN11/CN12 I/O Type Description”.
rfo
rfo
8531
BSC:
Section 13.1 ”Description”, updated introduction text.
Section 13.4.1 ”Boot Sequence Configuration Register”:
- renamed the BOOTKEY bitfield to WPKEY
- WPKEY: replaced the bitfield description with a table
9006/rfo
RSTC:
Section 14.2 ”Embedded Characteristics”, removed the “AMBA™-compliant Interface” bullet and its
subbullet.
Section 14.4.4.4 ”Software Reset”, removed “Except for Debug purposes,...” from the “PERRST” bullet -
Section 14.5.1 ”Reset Controller Control Register”:
- EXTRST: updated the bitfield description
- KEY: replaced the bitfield description with a table
Section 14.5.2 ”Reset Controller Status Register”:
- RSTTYP bitfield description table: updated column headings to “Value/Name/Description”, replaced binary
configuration values with decimal values, and updated reset type names to ‘GENERAL_RST’, etc.
Section 14.5.1 ”Reset Controller Control Register”:
- KEY: replaced the bitfield description with a table
9043
9017
8271
9043
9043
9043
