48.4.4 Crystal Oscillator Characteristics
The following characteristics are applicable to the operating temperature range: T
A
= -40°C to 85°C and worst case of power sup-
ply, unless otherwise specified.
48.4.5 XIN Clock Characteristics
Notes: 1. These characteristics apply only when the Main Oscillator is in bypass mode (i.e. when MOSCEN = 0 and OSCBY-
PASS = 1) in the CKGR_MOR register. See “PMC Clock Generator Main Oscillator Register” in the PMC section.
2. Do not exceed 3.6V
Table 48-8. Crystal Characteristics
Symbol Parameter Conditions Min Typ Max Unit
ESR Equivalent Series Resistor Rs
fundamental @3MHz
fundamental @8MHz
fundamental @16MHz
fundamental @20MHz
200
100
80
50
Ω
C
M
Motional Capacitance 8fF
C
S
Shunt Capacitance 7pF
Table 48-9. XIN Clock Electrical Characteristics
Symbol Parameter Conditions Min Max Units
1/(t
CPXIN
) XIN Clock Frequency 50 MHz
t
CPXIN
XIN Clock Period 20 ns
t
CHXIN
XIN Clock High Half-period 0.4 x t
CPXIN
0.6 x t
CPXIN
ns
t
CLXIN
XIN Clock Low Half-period 0.4 x t
CPXIN
0.6 x t
CPXIN
ns
C
IN
XIN Input Capacitance
(1)
25 pF
R
IN
XIN Pull-down Resistor
(1)
500 kΩ
V
XINLOW
XIN Low Voltage
(1)
-0.3V 0.3 x VDDOSC
(2)
V
V
XINHIGH
XIN High Voltage
(1)
0.7 x VDDOSC VDDOSC+0.3
(2)
V
