48. Electrical Characteristics
48.1 Absolute Maximum Ratings
48.2 DC Characteristics
The following characteristics are applicable to the operating temperature range: T
A
= -40°C to +85°C, unless otherwise specified.
Table 48-1. Absolute Maximum Ratings*
Junction Temperature..................................................125°C
*NOTICE: Stresses beyond those listed under “Absolute Maximum
Ratings” may cause permanent damage to the device.
This is a stress rating only and functional operation of
the device at these or other conditions beyond those
indicated in the operational sections of this specification
is not implied. Exposure to absolute maximum rating
conditions for extended periods may affect device reli-
ability.
Storage Temperature..................................-60°C to +150°C
Voltage on Input Pins
with Respect to Ground.....-0.3V to VDDIO+0.3V(+ 4V max)
Maximum Operating Voltage
(VDDCORE and VDDPLL) ...........................................1.2V
(VDDIOM, VDDIOPx, VDDOSC, VDDANA,
VDDNF, VDDUSB, VDDFUSE, and VDDBU) ...............4.0V
Total DC Output Current on all I/O lines...................350 mA
Table 48-2. DC Characteristics
Symbol Parameter Conditions Min Typ Max Units
T
A
Operating Temperature
(Industrial)
-40 +85 °C
V
VDDCORE
DC Supply Core 0.9 1.0 1.1 V
V
VDDBU
DC Supply Backup 1.8 3.6 V
V
VDDPLL
DC Supply PLL 0.9 1.0 1.1 V
V
VDDOSC
DC Supply Oscillator 1.65 3.6 V
V
VDDIOM
DC Supply EBI I/Os 1.65/3.0 1.8/3.3 1.95/3.6 V
V
VDDNF
DC Supply NAND Flash
I/Os
1.65/3.0 1.8/3.3 1.95/3.6 V
V
VDDIOP0
DC Supply Peripheral I/Os 1.65 3.6 V
V
VDDIOP1
DC Supply Peripheral I/Os 1.65 3.6 V
V
VDDANA
DC Supply Analog 3.0 3.3 3.6 V
V
VDDUSB
DC Supply USB 3.0 3.3 3.6 V
V
VDDFUSE
DC Supply Fuse Box 3.0 3.6 V
V
IL
Input Low-level Voltage
V
VDDIO
from 3.0V to 3.6V -0.3 0.8 V
V
VDDIO
from 1.65V to 1.95V -0.3 0.3 x V
VDDIO
V
V
IH
Input High-level Voltage
V
VDDIO
from 3.0V to 3.6V 2 V
VDDIO
+ 0.3 V
V
VDDIO
from 1.65V to 1.95V 0.7 x V
VDDIO
V
VDDIO
+ 0.3 V
