SAM9N12/SAM9CN11/SAM9CN12 [DATASHEET]
11063K–ATARM–05-Nov-13
46.5.6 SHA Interrupt Status Register
Name: SHA_ISR
Address: 0xF001401C
Access: Read-only
DATRDY: Data Ready
0: Output data is not valid.
1: 512-bit block process is completed.
DATRDY is cleared when a Manual process occurs (START bit in SHA_CR) or when a software triggered hardware reset of the
SHA interface is performed (SWRST bit in SHA_CR).
URAD: Unspecified Register Access Detection Status
0: No unspecified register access has been detected since the last SWRST.
1: At least one unspecified register access has been detected since the last SWRST.
URAD bit is reset only by the SWRST bit in the SHA_CR control register.
URAT field indicates the unspecified access type.
URAT: Unspecified Register Access Type
Only the last Unspecified Register Access Type is available through the URAT field.
URAT field is reset only by the SWRST bit in the SHA_CR control register.
31 30 29 28 27 26 25 24
––––––––
23 22 21 20 19 18 17 16
––––––––
15 14 13 12 11 10 9 8
URAT URAD
76543210
–––––––DATRDY
Value Description
0x0
Input Data Register 0 to 15 written during the data processing in DMA mode. (URAD=0x1 and URAT=0x0 can
occur only if DUALBUFF is cleared in SHA_MR)
0x1 Output Data Register read during the data processing.
0x2 Mode Register written during the data processing.
0x3 Write-only register read access.
